Technical parameters
Measurement range | Internal resistance：0.000mΩ-99.999mΩ |
Minimum measurement resolution | Internal resistance：0.001mΩ |
Measurement accuracy | Internal resistance：±0.5%rdg ±6dgt |
Power supply | 11.1V,2400mAh, Rechargeable lithium battery |
Power consumption | Can work continuously for 8 hours |
Storage capacity | 64Mbit Flash+4G SD card |
Display | 5-inch color touch screen |
Size | 220 x 170 x 52mm |
Net weight | 1.1Kg |
Nickname: Battery Resistance Tester; Battery Internal Resistance Tester
Main Functions
1. Quickly measure battery voltage, internal resistance, connection resistance, oscilloscope (optional) and other parameters online.
2. Alarm for battery internal resistance and voltage exceeding limit.
3. The meter adopts anti-AC ripple noise circuit technology to make the meter test results more accurate and the test results more consistent.
4. The meter has a fast re-test function. If human error is found during the test, it can be re-tested and automatically overwrite the original data.
5. The meter prestores more than 200 reference internal resistance values, which can also be customized.
6. The battery parameters are all numbered in groups, which is convenient for data management.
7. Supporting powerful computer battery status intelligent analysis software to realize the tracking and analysis of battery "medical records".
8. The automatic test mode is convenient for users to measure.
(1) Automatically analyze and judge the "deteriorated" state of the battery.
(2) Form a historical record database to describe the battery status curve.
(3) Comparative analysis of the same group of batteries.
(4) All battery graded management (excellent, good, medium and poor).
