Technical parameter
Power Supply | Three-phase four-wireAC380V | |
Output voltage and current | Three phase AC100V Output(Fixed value) | One group |
Three phaseAC0～10A Output(100V，Adjustable value) | One group | |
AC voltage output AC 0～400V, when 220V, the current is less than10A | One group | |
DC operating voltage output DC 0～260V | One group | |
Single phaseAC220V Output(fixed value, socket) | Two group | |
Three phaseAC380V Output(Fixed value, terminal) | One group | |
DC fixed voltage 24V, 36V, 110V, 220V output | One group | |
Size | 550×750×800mm3 | |
Weight | 45kg | |
Nickname:Switchgear Test Bed, Switchgear Test bench, Switchgear Tester
Features
1. The power-on test bench for high and low voltage switchgear integrates a variety of AC and DC power supplies
2. It is convenient to detect the switch cabinet and greatly improve the work efficiency
